From China’s engineering hubs to the world’s most critical infrastructure projects, we deliver reliable, sustainable machinery products and one-stop services across all continents.
Performance Features
- Equipped with brand-name power units, guaranteed quality and excellent performance
- Fitted with energy-saving LED lamps, high luminous flux, energy-efficient
- High-performance motor, one-touch electric lifting and lowering
- 5-section lifting pole, galvanized lamp mast, anti-fall and corrosion-resistant
- Three wind-resistant outriggers for stable support
- Integrated control panel with rainproof cover
- 7-meter maximum lifting height, adjustable lighting angle, long irradiation distance
- Large-capacity fuel tank for extended working endurance
The 7m Mobile Lighting Tower is widely used in:
1.Road and highway construction
2.Municipal engineering projects
3.Emergency rescue operations
4.Mining and industrial sites
5.Outdoor maintenance work
6. Railway construction
7.Infrastructure projects
8.Temporary outdoor lighting
9.Disaster recovery operations
10.Remote field operations
High Brightness LED Lighting
Equipped with high-efficiency LED lamps, providing stable and wide-range illumination.
7m Adjustable MastMulti-section telescopic mast can extend up to 7 meters for wider lighting coverage.
Long EnduranceLarge-capacity fuel tank ensures long-time continuous operation at outdoor job sites.
Sturdy & Durable StructureHeavy-duty steel structure with anti-rust surface treatment, suitable for harsh environments.
Easy TransportationTrailer-type design enables convenient movement and on-site deployment.
Electric Lifting，Adopts electric lifting system, which is easy and labor-saving to operate.
1.Portable mobile lighting tower design
2.2 LED lights or 4 LED lights optional
3.Reliable gasoline and diesel generator options
4.Strong wind resistance performance
5.Electric lifting system, easy to operate
6.Stable lighting output for outdoor projects
7.Anti-corrosion surface coating
8.Long lifespan LED lighting system
9.Suitable for remote construction environments
We specialize in outdoor emergency and construction lighting equipment manufacturing.
Every mobile lighting tower is tested before delivery to ensure stable performance.
We support customized solutions based on project and market requirements.
Professional international logistics and export support for global customers.
Efficient production management ensures reliable lead time and bulk order support.
We provide flexible OEM and ODM solutions for global distributors, wholesalers and project contractors.
Customization options include:
1.Logo printing
2.Product color
3.Engine / Generator Brand Configuration
4.Lamp quantity
5.Packaging design
Customized logo, color, lighting configuration and power options are available.
Model | 4EVA4000 | ||
long(mm) | 2180（1160,Detachable trailer bar） | ||
wide（mm） | 1130 | ||
high（mm） | 2700(2300,Separate a pair of overhead lights) | ||
Pole Master (all pulled to the top)(m) | 7 | ||
weight（Kg） | 550 | ||
Engine Brand | CHANGCHAI | ||
Engine Model | 186F | ||
Frequency（HZ） | 50/60 | ||
Rotating speed（rpm） | 3000/3600 | ||
Power（KVA） | 5 | ||
Number of cylinders | 1 | ||
diesel engine characteristic | Four stroke，Inline，Air-cooled diesel engine | ||
Combustion type | Direct injection | ||
Engine suction | Natural inhalation | ||
Emission level | Tier 4 | ||
Alternator | Brushless and single-phase | ||
Generator insulation | H class | ||
Output jack（V） | 230 / 240-120 VAC | ||
Fuel tank capacity | 38 liters (10 US gallons) | ||
Continuous working time | 25 hours | ||
Headlights | (E40/E39,GEWISS) Metal Halide | LED | |
Lamps power x quantity | 4×1000W | 4*400W | 2*200W |
Luminous flux | 440000/224000lm | ||
Light pole tilt | ------- | ||
Telescopic rod | electric | ||
Stabilize the leg | manual | ||
Suspension & Brakes | Hexagonal rubber shaft without brake | ||
tie down | Ball or O-ring | ||
Output jack | 1 Piece (230V,10A) | ||
Tire and rim size | 13’’ | ||
sound pressure | 78dB(A) It's 7 meters away | ||
One 40'height cabinet maximum most (sets) | 26 | ||
Standard color | Housing ：Green / yellow；car body：Black / gray Ledge：Galvanized Light Poles Traction Poles and Support Legs | ||
The mast can extend up to 7 meters.
2 LED lights and 4 LED lights or metal halogen bulbs configurations are available.
Yes, OEM and ODM customization services are supported.
They are widely used in construction, highway maintenance, mining, emergency rescue and municipal projects.
Kubota, Yamaha ,Changchai generator options are available.
We supply portable mobile lighting towers to customers worldwide for construction, infrastructure and emergency applications. With reliable product quality and professional export service, we support distributors, contractors and engineering companies with stable long-term cooperation.
